2 Way Solenoid Valve, 1/2" 3/4" 1" Port Size , Brass Body, DC 9W
High Quality Normally Closed electric solenoid valve, for water, air or oil
Working temperature range: -5℃-150℃
It's applicable in many fields: Irrigation controls (garden, farm,etc.), liquid controls ( pipeline, artificial river etc. and air controls ( lab, factory, etc.)
We have solenoids available in AC/DC and various size NPT threads as welll
SLG Series 2/2 Solenoid Valve | |||
Model | SLG5404-15E2 | SLG5404-20E2 | SLG5404-25E2 |
Working medium | Air ,Water,Oil | ||
Acting Type | Pilot type,N.C | ||
mm/orifice size | 12 | 20 | 25 |
KV Value | 2.0 | 5.0 | 10.0 |
Port Size | 1/2" | 3/4" | 1" |
Working Pressure(Bar) | Gas:1~50;liquid:1~50 | Gas:1~40;liquid:1~25 | Gas:1~40;liquid:1~25 |
Max.Pressure Resistance | 75 | 60 | |
Voltage Range | Power Consumption | ||
Working Temperature(°C) | -5~150 | ||
Power Consumption | AC:5.5VA DC:9W | ||
Valve boby Material | Brass | ||
Seal material | PTFE | ||
